Allen & Heath XONE:96 hire

£60.00 + VAT per day

£180.00 + VAT per week

The Allen & Heath XONE:96 is the long awaited follow-up to the industry standard XONE:92 DJ mixer.



6 channel club DJ mixer (4 x line/phono channels + 2 x stereo line/mono mic).



2 x aux sends/returns for output to external FX units. 4 stereo return channels (A+B selectable to be mic, stereo return or USB A/B return)



Master 2 output with independent volume control



3.5mm and 6.3mm jack headphone outputs



Dual 32-bit USB soundcard (24 Channels @ 96kHz) with Traktor Scratch certification right out of the box



4-band EQ – total kill on HF and LF, wide Q for cut, narrow Q for boost



Independent booth output on 6.3mm jack with 3 band EQ



2 x independent filters across all channels selectable between low pass, band pass and high pass. Adjustable “crunch” harmonic distortion control for each.



The Allen & Heath XONE:96 is supplied with IEC power cable and flight-case.



We also have other Allen and Heath DJ mixers available to hire. Check out our DJ equipment page for other models.



Technical specs:

  • Type Analogue
  • Channels 6 + 2
  • EQ
    Channel 1-4, 4-Band EQ
    Channel A-B, 3-Band Parametric EQ
  • USB Soundcards Dual 24 Channel (12 in / 12 out)
    Hi-Speed USB2.0 / Mac Class Compliant
    32bit / 96kHz
    MIDI over USB
  • Line Inputs 4 x RCA (CH 1-4)
    4 x 1/4″ TRS (CH A-D) Mono/Stereo
  • Phono Inputs 4 x RCA (CH 1-4)
    LN/PH Switch for DVS
  • USB Inputs 6 x USB (CH 1-4 + CH A – CH B)
  • Mic Input 2 x XLR
  • Master Output 1 x XLR (Balanced)
  • Master 2 Output 1 x 1/4″ TRS (Balanced)
  • Booth Output 1 x 1/4″ TRS (Balanced)
  • Record Output 1 x RCA (Un-balanced)
  • Master Insert 1 x 1/4″ TRS
  • MIDI Out 1 x 5-Pin DIN
  • Send/Return I/O
    2 x 1/4″ TRS Send
    4 x 1/4″ TRS Return
    1 x LN/Hi-Z Switch (SND1/RTNA)
  • Filter
    2 x VCF Filter
    HPF / BPF / LPF
    Adjustable Frequency & Resonance
    Assignable CH 1-4 + CH A-B
    CRUNCH (Controlled Harmonic Signal Distortion)
  • X-Link 1 x RJ45
  • Headphones
    2 x 1/4″
    2 x 3.5mm
    Split Cue Monitoring
  • Channel Faders 60mm VCA / Replaceable
  • Chanel Meters 9 Segment LED
  • Channel Fader Curve 3 Types
  • X-Fader InnoFADER / 45mm VCA / Replaceable
  • X-Fader Curve 3 Types
  • Earth Ground Terminals x 2
  • Headroom 20dB
  • AC Mains
    100 to 240V
    AC 50/60Hz
    Consumption 45W max
  • Mains Adaptor 3 pin IEC socket
  • Height 109mm / 4.3″
  • Width 336mm / 13.25″
  • Depth 410mm / 16.2″
  • Weight 7kg / 15.4 lbs.
